Fiber Hermetic Feedthru+FA+MPO Assembly

3V TECHNOLOGY is a leading manufacturer for customized optical passive components.Our featured products are below:

1)Fiber Lens(to polish the fiber endface’s degree as customized)

2)Metallized fiber assembly(Au-palting)

3)Fiber hermetic feedthrough

4)Cutomized fiber array/PM fiber array

5)PM patchcord/PM-MT/PM-MPO

Description

3V TECHNOLOGY is a leading manufacturer for customized optical passive components.Our featured products are below:

1)Fiber Lens(to polish the fiber endface’s degree as customized)

2)Metallized fiber assembly(Au-palting)

3)Fiber hermetic feedthrough

4)Cutomized fiber array/PM fiber array

5)PM patchcord/PM-MT/PM-MPO



Metallized Fiber Device and Hermetic Feedthrough

For highly reliable optical modules, we provide multi-channel metallized  fiber array with hermetic feedthrough.

V-groove’s material Quartz/Tempax or customize
Connector Type(Optional) LC/FC/SC/MU/MPO or customize
Endface Polished-Angle 0-50 degree or customize
Plating Layer Ni:5-10um;Au:0.5-1.0um or customize
Plating Position The middle(1-10mm);The front(1-30mm) or customize
Package Material for Feedthru Glass,Kovar( 4J29) ,SUS or customize
Package Type for Feedthru Glass,Metal sealing
Fiber type SM/MM/PM or customize
Fiber Channal 1CH/2CH/4CH/8CH/12CH/48CH or customize
Core Pitch(um) 125,175,250 or customize
Stress Rod’s angle 0 degree/90 degree or customize
PER(dB) ≥18 or customize
Insertion Loss(dB) ≤0.2
Return Loss(dB) ≥50
Hermeticity 1.0E-8ccHe/s;1×10-9M Pa·m3/s
