Optial Fiber Endface Angle Polishing(Angle-polished Fiber)

Angle-polished lensed fiber is produced by precision polishing techniques to abtain different angles tip,which mainly to reduce the light return or change the optical transmitted direction.

Description

Angle-polished Lensed Fiber:

Angle-polished lensed fiber is produced by precision polishing techniques to abtain different angles tip,which mainly to reduce the light return or change the optical transmitted direction.

Product Application:

-Mainly used for laser coupling.
-PLC device coupling.
-Side pupm optical fiber combiner.
-Endoscope illumination.

Product Features:

-3V TECHNOLOGY has unique fiber polishing techniques to produce angle tip as high as to 75 degree,and with different coating design,we can satisfy most of customer requirement.

-±0.2 degree polishing angle precision at best.

-Super clean tip finishing surface.

-AR/Hi-reflection coating.

-Au-plated metallizing process

Fiber Type Single-mode,multimode,large-core fiber or customer specified
Fiber Model SMF-28,Hi1060,Nufern 105/125 MM fiber,Customize
Fiber Tip Stripped Length Customize size±0.5mm,Customize
Polishing facet to fiber axis 15-90 degree as customer’s requested
Length of the Fiber 50-200cm,Customize.
Coating Parameter Anti-reflection coating,R<0.2%@Center wavelength±50nm.

We can support customized order with my 10years experience in manufacturing lensed fiber.welcone to contact me freely:
