This is a deal case for us ,clients satisfied with the quality .
Specification:
1: 2 channels with 392um pitch
2:PM15Y-80-U16 fiber ,1.5 meter long
3: facet 15 degree +/-0.5 degree angle polishing (Horizontal direction)
4:stress rod angle 90 degree +/-3degree (strict can be +/-2 degree) alignment
5:no connectors at the other side of the fiber
6:ILIL<0.3dB
7:ER≥22dB
8:Tiny package box size 4mm(length)x2.07mm(width)x2mm(height)
9:Pitch value tolerance :+/-0.5um（Adjacent pitch，+/-1um for entire pitch)
We have the best teconology team ,top class machines and great service , Welcome to negotiate and cooperate with you。
